F 1200+ system High-performance tilt and turn hardware system for daily ventilation for standard to very large window elements
- Achieves the full opening width of 180 mm for all leaf heights
- Ventilation with variable adjustment – from gap ventilation to the tilted end position
- Safe use thanks to limitation of bottom opening width and authorised operation of the turn function
- Excellent operating comfort thanks to non-powered, barrier-free and safe operation, variable drive positioning and user feedback
- Brightness sensor adjusts illumination of the control panel to the ambient brightness
- Proximity sensor activates the control panel when the user approaches
- Optional extendible fitting system with aid of vertical and horizontal central locking systems in accordance with leaf size
- Safe locking for almost any number of bolt points
High-performance tilt and turn hardware system for daily ventilation for standard to very large window elements
Application Areas
- Automation of large and heavy windows for natural ventilation
- Can be used for natural ventilation (24 V) in the façade area
- For inward opening turn and tilt and tilt windows
- Installation on aluminium windows
- Leaf and frame installation
Installation situations in reference objects and videos
F 1200+ window drive
Modern façade design calls for floor-to-ceiling window elements that ensure maximum daylight and comfort in rooms. The F 1200 is the ideal window fitting system for this trend, allowing for the operation of large and heavy turn-and-tilt windows. It provides a pleasant and comfortable indoor climate through natural ventilation – even at airy heights. The new F 1200+ drive is now available for convenient opening and locking of large windows, making operation even easier, faster and safer. © GEZE GmbH
F 1200+ window drive
A proximity sensor activates the control panel as soon as a person approaches. The capacitive touch buttons and an LED display make operation a breeze. An additional brightness sensor adjusts the LED display to the lighting in the room, and provides information both on the status of the drive and the opening width of the window. © GEZE GmbH
F 1200+ window drive
Operate heavy windows easily and safely: The F 1200+ has a very powerful motor that can turn and tilt even heavy window elements up to 200 kg leaf weight – while remaining extraordinarily quiet. © GEZE GmbH
Technical data
| F 1200+ system | |
| Leaf width (min.) | 750 mm |
| Leaf width (max.) | 2400 mm |
| Leaf height (min.) | 750 mm |
| Leaf height (max.) | 3500 mm |
| Leaf weight (max.) | 200 kg |
| Panel weight (max.) | 150 kg/m² |
| KNX ability | Yes |
| Opening speed ventilation | 11 mm/s |
| Opening width (max.) | 180 mm |
| Overload cut-off | Yes |
