TS 5000 L

Guide rail BG wall mounting TS 3/5000 L Guide rail for wall installation with lever, opposite hinge side

Gleitschiene BG Sturzmontage TS 3/5000 L Gleitschiene (20,7mm) zur Montage im Sturz auf Bandgegenseite für TS 5000 L und TS 3000.
  • With riveted slide block
Contact us

Application Areas

  • Single leaf doors
  • Installation on the opposite hinge side
  • Right and left single-action doors
  • Lintel installation fixing to the top

Technical data

Guide rail BG wall mounting TS 3/5000 L
Length 550 mm
Width 30.5 mm
Height 20.7 mm
opening restrictor upgradable Yes
Hold-open function Optional
Hold-open device can be overridden Yes

Variants & Accessories
